Z Cross Plot Data Definition Options

This option governs a couple of additional settings for the plot, including setting the labels for the axes and the symbol size.

The Z Data Cross Plot Data Definition X-Y Axis tab

Axis Labeling Mode

This dropdown determines how Petra labels the X and Y axes.  The options include:

Zone Name - Data Item - Item Description

Zone Name - Data Item

Zone Name - Item Description

Item Name - Item Description

Item Name

Item Description

Symbol Size (Inches) - This option sets the size of the individual data points on the cross plot.

Do Not Use LOG Scale to Compute Defaults - This option forces Petra to always use linear scales when setting defaults on the X-Y Axis tab and the Z-Axis tab.
